Model / Part No.
10DX3111EDE07P1A2LA22121
Product ID
#111
The ABB 10DX3111EDE07P1A2LA22121 belongs to the 10DX3111 magnetic flowmeter family covered by ABB installation manuals for the MAG-X Series 3000 and 50XM pulsed-DC magnetic flowmeter line. ABB documentation groups 10DX3111 with 10DX2111 and 10DX3112 in the pulsed DC family, supports remotely mounted converters such as the 50XM2000 field-mount housing, and lists design levels A and G for sizes 14 through 24 inches. The EDE07P1A2LA22121 suffix distinguishes this unit's liner, electrode, signal and process-connection options from other 10DX3111 variants such as 10DX3111ADD17P1A2BK24321. ABB does not publish a public decoding table for the complete suffix, so those options should be confirmed against your existing meter before ordering.
| Manufacturer | ABB |
| Model Number | 10DX3111EDE07P1A2LA22121 |
| Family | 10DX3111 (pulsed DC magnetic flowmeter) |
| Product Type | Magnetic flowmeter primary with converter interface |
| Measurement Principle | Magnetic (Faraday) flow, pulsed DC |
| Liner / Electrode Material | Contact supplier for exact specifications (encoded in suffix) |
| Process Connection | Contact supplier for exact specifications (encoded in suffix) |
ABB MAG-X Series 3000 magnetic flow measurement with 50XM converters
The 10DX3111 base code is shared across option variants; suffixes such as EDE07P1A2LA22121 and ADD17P1A2BK24321 denote different constructions. Match the full suffix of your existing meter to guarantee identical configuration.
