Model / Part No.
1SAP180200R0101
Product ID
#180
The ABB 1SAP180200R0101 is the order code for the TK502 programming cable of the AC500 family: a 5 metre cable with a D-Sub 9 male connector on one end and a pluggable terminal (5-pin) on the other, used to connect programming and configuration tools to AC500 CPUs with terminal-style programming ports. Distributor datasheets record dimensions of 160 x 150 x 30 mm, weight 0.35 kg, indoor use IP20, operating range 0 to 60 degrees Celsius and lifecycle status Active. Listings across major distributors show consistent descriptions with stock. Match connector style against your CPU before ordering.
| Manufacturer | ABB |
| Model Number | 1SAP180200R0101 |
| Type Designation | TK502 |
| Length | 5 m |
| Connectors | D-Sub 9 male to pluggable terminal 5-pin |
| Dimensions | 160 x 150 x 30 mm |
| Weight | 0.35 kg |
ABB AC500 CPUs with pluggable-terminal programming port
TK502 (this code) ends in a pluggable terminal; TK501 (1SAP180200R0001) is D-Sub to D-Sub. Match the connector style your CPU requires.
