Status: Discontinued / Obsolete
Contact us for compatible replacement options.
This part is no longer manufactured. We can source limited stock or suggest alternatives — send inquiry below.
Model / Part No.
1SAP210000R0001
Product ID
#188
The ABB 1SAP210000R0001 is the order code for the TU506-FBP terminal unit of the AC500 S500 I/O family: a spring-contact terminal unit with an M12 fieldbus plug (FBP) interface and 24 VDC supply, recorded with EAN 4016779649209 in distributor catalogs. Dimensions are listed as 67.5 x 135 x 28 mm with weight 0.16 kg. ABB lifecycle documentation shows TU505 / TU506 class terminal units among products no longer produced but available as spares from remaining stock, so order early. Use TU506-FBP as the base unit for S500 I/O modules on FBP network configurations.
| Manufacturer | ABB |
| Model Number | 1SAP210000R0001 |
| Type Designation | TU506-FBP |
| Interface | M12 fieldbus plug (FBP) |
| Terminal Style | Spring-contact |
| Supply | 24 VDC |
| Dimensions | 67.5 x 135 x 28 mm; 0.16 kg |
ABB AC500 S500 I/O with FBP fieldbus
TU506-FBP (spring, M12 FBP) versus TU505-FBP (1SAP210200R0001, screw terminals); other variants: TU551/TU552-CS31 (CS31 bus), TU507/TU508-ETH (Ethernet). Match terminal style and network.
