Model / Part No.
1SAP220000R0001
Product ID
#198
The ABB 1SAP220000R0001 is the order code for the DC505-FBP digital module of the AC500 S500 I/O family: a combined 8 digital inputs and 8 digital outputs module (24 VDC, 0.5 A per output) with a fieldbus plug (FBP) interface, documented by ABB's own product pages as S500 I/O Digital Module 8DI/8DO 24VDC. Distributor catalogs record EAN 4016779649360, dimensions 100 x 150 x 70 mm and weight 0.164 kg, with unit-box packaging per ABB. Listings show stock across major distributors. The module wires to TU505-FBP / TU506-FBP terminal bases.
| Manufacturer | ABB |
| Model Number | 1SAP220000R0001 |
| Type Designation | DC505-FBP |
| Digital Inputs | 8 (24 VDC) |
| Digital Outputs | 8 (24 VDC, 0.5 A) |
| Interface | FBP (fieldbus plug) |
| Dimensions | 100 x 150 x 70 mm; 0.164 kg |
ABB AC500 S500 I/O with FBP fieldbus
DC505-FBP (this code) uses an FBP interface; DC551-CS31 variants (1SAP220500R0001 / R3001) use the CS31 bus. Match the bus of your terminal base.
